SICK DFS60A-S4PC65536 - Rotation-Measure/High-Density-Pulse-Output - IP65 M12 Alloy Solid Shaft Ultra High Res Rotary Encoder
DFS60A-S4PC65536 Ultra-High-Res HTL Incremental Encoder
The DFS60A-S4PC65536 is a 60mm Standard-tier incremental encoder featuring HTL 10-32V operation, 65536 pulses per revolution, clamp flange with blind hollow shaft, and IP65/IP67 protection rating.
Application & Precision Motion Control
Delivers ultra-high-resolution pulses for precision servo systems, CNC tables, and semiconductor equipment. The blind hollow shaft mounts directly on motor tails, while HTL output provides excellent EMI resistance—offering high-accuracy motion control without requiring absolute encoders.
Product Specifications
| Parameter |
Specification |
| Model / Order No. |
DFS60A-S4PC65536 / 1036726 |
| Product Type |
Incremental encoder, programmable |
| Pulses per Revolution |
65,536 (16-bit, programmable) |
| Output Interface |
TTL / HTL (programmable, factory TTL) |
| Supply Voltage |
4.5 … 32 V DC |
| Shaft Type / Diameter |
Solid shaft, face mount flange / 10 mm × 19 mm |
| Connection |
M12, 8-pin male, radial |
| Enclosure / IP Rating |
IP65 / IP67 |
| Operating Temperature |
-40 … +100 °C |
| MTTFd |
300 years (EN ISO 13849-1) |
